    Electronics - PCB101- Circuit Board, PCB designer soft skills development with PCB manufacturing understanding
    What you'll learn:
    How to quickly become a good PCB layout designer
    How does PCB design and PCB manufacturing affects each other
    Soft skills for PCB layout design
    PCB materials and stack-up
    Different types of PCBs
    Learn about different PCB FINISH
    Learn about different PCB colors
    How to choose the best PCB supplier
    Careers in PCB industry
    Quality in PCB field

    This is the basic (core) course in the series.
    This course is designed for new graduates in Electrical and Electronics field and junior engineers
    Anyone who is interested in learning more about PCB

    Develop your PCB design skills with a deep understanding of the PCB manufacturing industry

    With my 20+ years of PCB manufacturing experience, I will teach you things that would have taken you years to learn at your job.

    This course is designed for new graduates and new engineers so the topics are explained in a simple manner to the audience. The course covers lots of information and topics which would help you become a good designer. The skills beyond your software abilities.

    What You Will Learn:

    Different types of PCBs

    File formats used in PCB industry

    PCB materials and stack-ups

    Design Rule Checks

    Design for Manufacturing


    Soldermask and Silkscreen

    Array and Panelization

    How to reduce the cost of your PCB

    Understanding PCB Supplier capabilities

    How to find a good PCB supplier

    Quality in PCB

    Careers in PCB industry (PCB design, PCB manufacturing, PCB assembly)

    What to expect after finishing this course:

    You will have a better understanding of how PCB design and PCB manufacturing related to each other and how they affect each other.

    You will have a better understanding of career opportunities in different PCB fields.

    Somewhat understanding of how to read material data sheets

    YouTube Chanel

    Follow my YouTube channel "ElektroLynx" to take advantage of watching free videos related to this course. Videos cover topics like:

    Why are PCBs always Green ??

    What is the best Gerber Viewing software?

    How to load drill files correctly?

    PCB & PCBA Glossary videos

    ElektroLynx website
    ElektroLynx is my hobby website, not a company. On the website, you will find many articles related to the PCB industry. I will upload articles on regular basis. The website is fairly new therefore you may not see many articles right away. The site also has a blog section as well Forums. In the forums section, please feel free to ask and discuss any topic related to PCB.


    All future courses (PCB102, PCB201, and PCB202) will be offered as complementary (Free of Charge) to all of our PCB101 students.


    26-Jan-2020 Course released

    30-Jan-2020 English captions added
