    SolidCAM 2020 SP5 HF1 Multilingual for SolidWorks 2012-2021 (x64)

    SolidCam - a new generation CAD / CAM system developed by the Israeli company Solidcam Ltd (official distributor in Russia - Consistent Software). This system is a comprehensive solution for automating metalworking production. Using a wide set of SolidCam, the strategies of turning, milling, turning and milling and electro-erosive processing technologist can prepare the necessary set of control programs for the product in a short time.

    Functionality solidcam
    Support 64bit calculations due to the availability of a special version for SW 64bit
    2.5-coordinate milling
    SolidCam provides high efficiency and accuracy of 2,5-coordinate milling parts. Different strategies for processing such elements such as contour, sample (with islands) and grooves, as well as various types of holes are supported: drilling, cenching, threading, etc. The system has a wide range of features of the 2,5-coordinate processing of analytical surfaces.
    3-coordinate milling
    Solidcam provides a wide range of means that can be effectively used to treat products with complex geometry (stamps, molds) and parts of the prismatic form. As a geometry for 3-coordinate processing, a three-dimensional surface or solid-state model is used. The system supports various types of roughing and finishing strategies, such as raster processing with a predetermined or automatically detected raster angle, processing on the equidistant, projection processing, watering processing, etc.
    In addition to the already listed features of 2.5 and 3-coordinate processing, SolidCam offers tools to identify and reflecting areas not processed on previous transitions. It is possible to create a database of typical technological processes. Once created, such a parametric process can be repeatedly used further, which significantly reduces production preparation time, improves the reliability of the developed programs, unifies the style of technological developments, guarantees the use of only optimal processing technologies and ensures the independence of production from the human factor. The lack of incisions are guaranteed by the presence of means of control and visualization of machining.
    Multiple treatment
    SOLIDCAM offers various means of creating multi-axis processing control programs on 4- and 5-coordinate processing centers. The model is set to a user-defined processing plane, after which the system automatically calculates all the necessary displacement and rotation parameters for a zero part. As a result, the preparatory and final transition time is significantly reduced and the processing accuracy increases.
    Turning and turning and milling
    SolidCam has a wide range of features to automate the creation of control programs for turning and turning and milling processing. SolidCam supports various types of tools, which allows you to effectively produce longitudinal sharpening, trimming of the end, processing grooves, etc. In addition, SolidCam allows you to automatically produce rough and finite processing of complex contours. Support for the rotating tool allows milling and drilling transitions to process centers.
    Electroerosion treatment
    The proposed SolidCam strategy set of wire electric erosion processing allows processing of external and internal circuits with a constant and variable tilt angle. The possibility of 4-axis processing is provided. A special algorithm prevents the drop in the treated material. SolidCam provides the user to the physical processing control tools across the entire carriage movement path.

    Blossomy: 64bit
    Interface language: Multilingual (Russian is present)
    Chinese simplified, chinese traditional, czech, danish, dutch, english, french, german, hebrew, hungarian, italian, japanese, korean, polish, portuguese, russian, spanish, turkish
    Tabletka: Present (Team Solidsquad-SSQ)
    System requirements:
    Preset SolidWorks 2012-2021 64bit Only

    Size File: 4.68 GB

    What News?
    Read: SolidCAM_Release_Notes_2020_SP5_HF1.pdf
